| Product Name: | Aluminum Honeycomb Core | Size: | 1220*2440mm Or Customized |
|---|---|---|---|
| Surface: | Smooth | Foil Thickness: | 0.04mm-0.2mm |
| Material: | 3003 And 5052 Aluminum | Color: | Silver |
| Thickness: | 2mm-200mm | Cell Size: | Customized |
| Side Length: | Customized | Usage: | Ceiling Panel |
| High Light: | Ceiling Panels Aluminum Honeycomb Core,Lightweight Aluminum Honeycomb Panels,High Strength Honeycomb Aluminum Core |
||
Aluminum honeycomb core is a lightweight, high strength material used in a variety of applications. With a thickness of 2mm-200mm, A1 grade fireproofing and a smooth surface, it is the ideal solution for many projects. It has a cell size of 1.04mm-50mm and a high compressive strength , making it an incredibly strong material for its weight. Aluminum honeycomb core is the perfect material for any project that requires a light weight, high strength solution.
• Competitive Advantage
• Light weight
• High strength
• Super flatness
• Compression, shear and corrosion resistance
• Flatness
| Aluminum Honeycomb Core | |||
| Specifications | Side length (mm) | Foil Thickness (mm) | Density (kg/m³) |
| BHC3003-0.4-0.015L | 0.4 | 0.015 | 137 |
| BHC3003-0.5-0.015L | 0.5 | 0.015 | 137 |
| BHC3003-0.5-0.021L | 0.021 | 190 | |
| BHC3003-0.6-0.015L | 0.6 | 0.015 | 151 |
| BHC3003-0.6-0.021L | 0.021 | 158 | |
| BHC3003-0.8-0.021L | 0.8 | 0.021 | 118 |
| BHC3003-0.8-0.025L | 0.025 | 144 | |
| BHC3003-0.8-0.03L | 0.03 | 169 | |
| BHC3003-1-0.025L | 1 | 0.025 | 115 |
| BHC3003-1-0.03L | 0.03 | 137 | |
| BHC3003-1-0.04L | 0.04 | 183 | |
| BHC3003-1.5-0.03L | 1.5 | 0.03 | 90 |
| BHC3003-1.5-0.04L | 0.04 | 122 | |
| BHC3003-1.5-0.05L | 0.05 | 152 | |
| BHC3003-1.83-0.04L | 1.83 | 0.04 | 99 |
| BHC3003-1.83-0.05L | 0.05 | 123 | |
| BHC3003-1.83-0.06L | 0.06 | 148 | |
| BHC3003-2-0.04L | 2 | 0.04 | 90 |
| BHC3003-2-0.05L | 0.05 | 113 | |
| BHC3003-2-0.06L | 0.06 | 135 | |
| BHC3003-2.5-0.04L | 2.5 | 0.04 | 74 |
| BHC3003-2.5-0.05L | 0.05 | 92 | |
| BHC3003-2.5-0.06L | 0.06 | 110 | |
| BHC3003-3-0.04L | 3 | 0.04 | 61 |
| BHC3003-3-0.05L | 0.05 | 76 | |
| BHC3003-3-0.06L | 0.06 | 91 | |
| BHC3003-3-0.08L | 0.08 | 122 | |
| BHC3003-3.5-0.04L | 3.5 | 0.04 | 55 |
| BHC3003-3.5-0.05L | 0.05 | 68 | |
| BHC3003-3.5-0.06L | 0.06 | 82 | |
| BHC3003-3.5-0.08L | 0.08 | 110 | |
| BHC3003-4-0.04L | 4 | 0.04 | 46 |
| BHC3003-4-0.05L | 0.05 | 57 | |
| BHC3003-4-0.06L | 0.06 | 68 | |
| BHC3003-4-0.08L | 0.08 | 92 | |
| BHC3003-5-0.05L | 5 | 0.05 | 46 |
| BHC3003-5-0.06L | 0.06 | 54 | |
| BHC3003-5-0.08L | 0.08 | 72 | |
| BHC3003-5-0.1L | 0.1 | 91 | |
| Alloy | Al3003 and Al5052 | ||
| Supply form | Unexpanded (block, strip) or expanded(slice) | ||
| Unperforated | |||
• Building materials industry
• Lighting industry
• Industry
• Ship and so on
Aluminum Honeycomb Core Technical Support and Service
We are dedicated to providing our customers with the highest quality aluminum honeycomb core products and services. Our knowledgeable and dedicated technical support team is available to answer any questions you may have about our aluminum honeycomb core products. We are committed to providing you with prompt and accurate information so that you can make the best decisions for your project.
Our technical support and service team is available to help answer your questions and provide guidance throughout the design process. We can provide you with guidance on the best material for your application as well as provide you with assistance in the selection of the right aluminum honeycomb core for your project. We are also available to provide you with assistance in the manufacturing and installation process.
We are committed to helping you get the most out of our aluminum honeycomb core products. If you have any questions or concerns, please do not hesitate to contact our technical support and service team.
Q1. What is micro-porous aluminum honeycomb core usd for?
A: The micro-porous aluminum honeycomb core which has excellent rigidity and is one of the best metal wall materials. It has been widely used in the decoration of modern architecture, trains, automobiles, shipbuilding and building materials industry, lighting industry, printing machine platform and so on.
Q2. What are the advantages of micro-porous aluminum honeycomb core?
A: Micro-porous aluminum honeycomb core has the advantages of light weight-high strength, high surface flatness, environmental protection and no pollution.
Q3. What is the packaging method of micro-porous aluminum honeycomb core?
A: Micro-porous aluminum honeycomb core of samples are packed in cardboard and bulk orders are packed in plywood cases.
